- Size Guide
- Frame: Alloy frame AL6061
- Fork: Suntour Nex suspension fork 56mm travel
- Headset: Low Stack semi integrated
- Shift Levers: Deore 10 speed
- Left Shift Lever: Bosch Intuvia Controller 1270016724
- Brake Levers: Tektro T285 Hydraulic Disc brake
- Rear Derailleur: Deore 10 speed
- Brakes: Tektro T285 Hydraulic Disc brake
- Chainwheel: 38T for Bosch Gen 3
- Crankset: Raleigh Alloy BOSCH crank set 55017489
- Bottom Bracket: Bosch Integrated in motor
- Cassette: Shimano 10 speed 11-34 cassette
- Chain: KMC 10 speed
- Pedals: Comfort Pedals with Anti Slip 2501840300
- Front Wheel: Alloy Double wall, 36 spoke, 700c on Alloy disc hub
- Rear Wheel: Double Wall rim 36 hole 700c on alloy disc hub
- Front Hub: Alloy 36 hole black disc QR
- Rear Hub: Alloy cassette Hub 36 hole disc QR
- Rims: Black 36 hole disc brake compatible
- Tyres: Mitas 700C x 42 with reflective stripe and double duty puncture protection
- Inner Tubes: 700Cx 38 car type valve
- Motor: Bosch Active +
- Battery: Bosch Power Tube 500Wh, 36V
- Display: Bosch Intuvia multifunctional display with operation unit & push-assistance 1270020909
- Display bracket: Bosch Intuvia Display holder 1270020912
- sensor: Bosch Speed Sensor 1270020800
- Range: up to 225km from Eco mode
- Mudguards - set: Full mudguards
- Chainguard: Chain guard for Bosch Gen 3
- Rear Carrier: Alloy Rack
- Lighting: AXA FRONT LIGHT TRELOCK REAR WITH SLOWING FUNCTION
- Extras: Kick Stand, charger
|Riders Height||Frame Size|
|4'10"- 5'2" (148 - 158cm)||13" - 14" / X-Small|
|5'2"- 5'6" (158 - 168cm)||15" - 16" / Small|
|5'6"- 5'10" (168- 178cm)||17" - 18" / Medium|
|5'10" - 6'1" (178 - 185cm)||19" - 20" / Large|
|6'1" - 6'4" (185 - 193cm)||21" - 22" / X-Large|
|6'4" - 6'6" (193 - 198cm)||23" - 24" / XX-Large|
