- Size Guide
With a alloy frame and Shimano gears you off to a headstart before the Bosch motor as even kicked in.
- frame: Alloy frame AL6061
- suspension fork: Suntour Nex suspension fork 56mm travel
- headset: Low Stack semi integrated
- shift levers: Shimano 9 speed
- left shift lever: Bosch Intuvia Controller 1270016724
- brake levers: Tektro T285 Hydraulic Disc brake
- rear derailleur: Nexus 7 speed Hub gear
- brakes: Tektro T285 Hydraulic Disc brake
- chainwheel: 38T for Bosch Gen 3
- crankset: Raleigh Alloy BOSCH crank set 55017489
- bottom bracket: Bosch Integrated in motor
- freewheel/cassette: Shimano 22t sprocket
- chain: KMC Single speed
- pedals: Comfort Pedals with Anti Slip 2501840300
- front wheel: Alloy Double wall, 36 spoke, 700c on Alloy disc hub
- rear wheel: Double Wall rim 36 hole 700c on alloy disc hub
- front hub: Alloy 36 hole black disc QR
- rear hub: Shimano Nexus 7-speed disc
- rims: Black 36 hole disc brake compatible
- tyres: Mitas 700C x 42 with reflective stripe and double duty puncture protection
- inner tubes: 700Cx 38 car type valve
- stem: Adjustable angle Alloy
- handlebars: Comfort XLC Handlebar Black
- grips: Comfort Grip
- saddle: Selle Royal Milo + BZP5090
- seatpost: Alloy Seatpost 30.9
- seat clamp: 34.9 mm Quick Release Alloy Clamp
- motor: Bosch Active +
- battery: Bosch Power Pack Frame Mount 500Wh, 36V
- display: Bosch Intuvia multifunctional display with operation unit & push-assistance
- display bracket: Bosch Intuvia Display holder 1270020912
- sensor: Bosch Speed Sensor 1270020800
- range: up to 225km from Eco mode
- mudguards: Full mudguards
- chainguard: Chain guard for Bosch Gen 3
- rear carrier: Alloy Rack
- lighting: Axa Front Light Trelock Rear With Slowing Function
- extras: Kick Stand, charger
|Riders Height||Frame Size|
|4'10"- 5'2" (148 - 158cm)||13" - 14" / X-Small|
|5'2"- 5'6" (158 - 168cm)||15" - 16" / Small|
|5'6"- 5'10" (168- 178cm)||17" - 18" / Medium|
|5'10" - 6'1" (178 - 185cm)||19" - 20" / Large|
|6'1" - 6'4" (185 - 193cm)||21" - 22" / X-Large|
|6'4" - 6'6" (193 - 198cm)||23" - 24" / XX-Large|
